Cyberbond U 3600, UV Curable, Thixotropic / High Viscosity

SKU: N/A Categories: ,

For prices and availability, please login or register.

Product Description

Cyberbond U 3600

Cyberbond U 3600 is a thixotropic UV-curable adhesive that shows excellent bonding on glass, metal, and a variety of plastics. It combines high viscosity and hardness to make it an ideal potting compound, and bonds well on both similar and dissimilar substrates.

  • Monomer Base: Modified Acrylate
  • Viscosity: 10000-15000 (tx) mPa·s
  • Color: Clear / slightly cloudy
  • Optimal Wavelength: 325-420 nm
  • Fixture time*: < 2 seconds
  • Tensile Shear Strength (DIN EN 1465)
    • Polycarbonate: 4-5 N/mm²
    • Polycarbonate to Aluminium: 6-7 N/mm²
  • Block shear strength (CB work instruction)
    • Glass: > 18 N/mm²
    • Glass to Steel: 14-16 N/mm²
    • Glass to Aluminium: 15-17 N/mm²
  • Shore D Hardness: 76
  • Temperature Range: -30°C to 120°C
  • *CB work instruction, no gap, 4 mW/cm², lamp: LED Cyberlite4





Additional Information

Size

100g Bottle, 20g Bottle
